LK-701DCA
- PLC control for all electric and hydraulic functions
- Shuttle Type Automatic Job Length Feeding
- Floating shuttle vise for handling of bent job
- Automatic work height control and fast approach
- Power driven Chip removal Wire brush assembly
- Hydraulic Blade Tension
- Split main vise for better gripping
- Idler Wheel Motion Detector with Blade Stalling and Breakage shut off
- Roller Bearing / Carbide wear pad Blade guide system
- Bi Metal Bandsaw Blade
Description
Cutting Capacity | 701 |
Round (mm) | 701 |
Square (mm) | 701 x 701 |
Blade Dimensions(mm) | 8000 x 67 x 1.6 |
Blade Linear Speed(mm) | 20 -100 RPM WITH VFD |
Power Req. – Saw Drive (KW/H.P)(440V AC, 50Hz) | 7.5 /10/ 1440 RPM |
Hydraulic Motor (KW/H.P)(440V AC, 50Hz) | 1 /1.5/ 1440 RPM |
Coolant Pump | 0.12 / 0.16 / 2800 RPM |
Wire Brush Motor | 0.18 / 0.25 / 1440 RPM |
Hydraulic Tank Capacity | 80 |
Coolant Tank Capacity | 80 |
Shuttle Bar Feed Stroke (mm) | 350 |
Bundle Cutting W x H mm (*optional) | 700 x 500 |
Dimensions (LxWxH) mtr. | 3.3 x 1.4 x 2.3 |
Weight (kg) | 5000 |
OPTIONAL ACCESSORIES
- Bundle cutting attachment
- Chip Conveyor
- Job Roller Stand
- Wire Brush
- Bi-metal Bandsaw blade
- Variable Vise pressure for thin walled job
