| Cutting Capacity |
310 |
| Round (mm) |
310 |
| Square (mm) |
310 x 310 |
| Blade Dimensions(mm) |
4100 x 34 x 1.1 |
| Blade Linear Speed(meter/min.) |
20 -100 RPM |
| Power Req. – Saw Drive (440V AC, 50Hz) Kw/Hp |
2.2 / 3.0 / 1440 RPM |
| Coolant Pump (440V AC, 50Hz) Kw/Hp |
0.12 / 0.16 / 2800 RPM |
| Wire Brush Motor (440V AC, 50Hz) Kw/Hp |
0.18 / 0.25 / 1440 RPM |
| Hydraulic Tank Capacity (Leter) |
80 liter |
| Coolant Tank Capacity (Leter) |
80 liter |
| Shuttle Bar Feed Stroke (mm) |
350 |
| Bundle Cutting W x H mm (*optional) |
300 x 150 |
| Dimensions (LxWxH) mtr. |
2.3 x 2.5 x 1.3 |
| Weight (kg) |
2200 |
